Product Overview

This electric hydraulic mobile crane is a freely movable lifting equipment integrating traveling, lifting and amplitude variation. Powered by storage battery, it uses hydraulic cylinder to drive boom lifting. The whole machine can steer and move flexibly. It is widely used in workshops for hoisting steel pipes, moulds and heavy goods, solving material lifting problems in narrow spaces.

Core Advantages

• Fully Electric Operation: Electric travel and electric lifting, labor-saving and high efficiency.

• 360° Rotation: Flexible steering, suitable for multi-angle lifting tasks.

• Strong Load-bearing Capacity: Stable performance to meet heavy load hoisting requirements.

• Extendable Front Boom: Enlarges working radius to fit more working conditions.

• Safe & Reliable: Emergency stop protection and anti-drop hook safety latch.

Main Structure

• Weighted Chassis & Outriggers: Fork-type base with telescopic outriggers for stable operation and electric travelling.

• Hydraulic Boom Assembly: Foldable telescopic boom driven by hydraulic cylinder.

• Hydraulic Power Unit: Electric hydraulic pump station with powerful output.

• Storage Battery Pack: Large-capacity industrial rechargeable battery.

• Operation Control System: Handheld controller with lifting buttons and emergency stop.

• Hook & Chain Assembly: High-strength lifting hook with safety latch.

Technical Parameters

• Lifting Method: Electric hydraulic

• Travel Mode: Electric walking

• Rated Load: 500kg / 1000kg / 2000kg (optional)

• Lifting Height: 1.6m / 2.5m / 3m (optional)

• Working Radius: 1.2m / 1.6m / 2m (optional)

• Battery Voltage: 24V / 48V (optional)

• Travel Speed: 0-5km/h (adjustable)

Application Areas

Workshop hoisting, steel pipe transport, mould lifting, warehouse handling, goods hoisting and equipment installation.

Product Details

• Foldable Boom: Small footprint, easy storage

• Extendable Front Arm: Expands working range

• Telescopic Outriggers: Improve stability and anti-tipping performance

• Universal Wheels: Convenient movement and steering

Call to Action

Contact us for quotation, technical data and operation video of the electric hydraulic mobile crane.
